MOTOR PROTECTION RELAY
S-DXC Motor Protection Relay
Current range
0.25 TO 5 Amp0.8 TO 5 Amp4 TO 61 Amp40 TO 500 Amp400 TO 1200 Amp
Enquire about this productTECHNICAL INFORMATION
Know your product.
Product Details
| Aux Supply | 110 VAC OR 230 VAC OR 415 VAC |
|---|---|
| CT Type | In built Phase CTs up to 61 A & External Phase CTs above 61 A |
| Voltage Type | AC |
| Temperature | +10 TO 60 Degree C [Operation] |
| Display | Current Through 7 Segment LED |
| Mounting | Device DIN Rail Mount / Display Door Mount [Door Cutout 70 X 30 mm] |
Standard Features
- Selectable IT Curve OR Definite Time
- Selectable Trip Time for SPP & UL
- Selectable Rotor Locked Value
Optional Feature
- Separate Relay for U/L Protection
- 4 to 20mA Output
- Two Separate Relay output available
Protections
- Single Phasing Protection
- Over Load Protection
- Under Load Protection
- Phase-reversal Protection
- Phase Un-balance
- Locked Rotor Protection
- Short Circuit Protection
- Earth Fault Protection
Annunciations
- SPP
- O
- U
- Ph-r
- b
- L
- S
- E
